Item specifics
  • Built-in Firewall: Yes
  • Antenna Peak Gain: 5dBi
  • Wifi Frequence: 2.4G&5G
  • Brand Name: TP-Link
  • 2.4G Wi-Fi Transmission Rate: 1000 Mbps
  • Network Type: 4G/3G
  • Supports WDS: Yes
  • Wi-Fi Transmission Standard: 802.11a,802.11ac,802.11b,802.11g,802.11n
  • Supports WPS: Yes
  • LAN Ports: 4
  • Max. LAN Data Rate: 1000Mbs
  • Supports VPN: Yes
  • Wireless Security: WPA-PSK/WPA2-PSK
  • Wi-Fi Supported Frequency: 2.4G & 5G
  • Networking Protocol: IEEE 802.11b/g/n/ac
  • Model Number: Archer C7
  • Model: Archer C7 v2
  • Support VPN: Support
Product Description

Change Life will Change Fate

e589u-12 790s  e8377   image

4G ROUTER  Change wifi  modem + Router  4G  antenna

image            e8372 image

 cpe router    4G wifi modem  4g modem

note: whatsApp:+8615388793663

TP-LINK TL-WDR7500  v5  had add 16mb flash,

that same as the Archer C7 v2.0

AC1750  openwrt  firmware; english firmware

support 2.4g and 5ghz

breed u-boot

wdr7500 v5 1 wdr7500 v5 2 wdr7500 v5 3 wdr7500 v5 4 wdr7500 v5 6

TL-WDR7500
1    11AC, a new generation of wireless technology, better visual experience
2   2.4/5GHz dual-band wireless technology, the highest rate of up to 1.75Gbps
3    Gigabit wired port, network transmission speed is faster.
4.    6 single frequency antenna, signal broader coverage, better signal.

5    The  provides 2 USB interface, support network storage sharing, the multimedia server, FTP server and other functions
6.    IP bandwidth control function, free Internet bandwidth allocation
7.     WDS wireless bridging function, easy expansion of wireless network

8.  support 3g  4g  lte card modem



  2 USB interface  for  3G/4G lte router network









 TL-WDR7500


wdr7500 v3 openwrt 8wdr7500 v3 openwrt 1wdr7500 v3 openwrt 2wdr7500 v3 openwrt 3wdr7500 v3 openwrt 4wdr7500 v3 openwrt 5wdr7500 v3 openwrt 7

54_tl-wdr7500wdr7500-1wdr7500 2wdr7500 3wdr7500 4wdr7500 5



tp link-tl-wdr7500-1.jpgtp link-tl-wdr7500-2.jpgtp link-tl-wdr7500-3.jpg

wdr7500 8wdr7500 9






Protocol standard

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b; IEEE 802.11.ac; IEEE 802.11.a

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab;

Wireless rate

2.4GHz frequency range: 450Mbps

5GHz frequency range: 1.3Gbps

Interface

4 adaptive 10/100/1000M LAN port, support automatic turnover (Auto MDI/MDIX);

1 adaptive 10/100/1000M WAN port, support automatic turnover (Auto MDI/MDIX);

2 USB 2 interface.

Button

The power switch;

The QSS button;

The Reset button.

LED

The power indicator light;

SYS system indication;

2.4GHz wireless status indication;

5GHz wireless status indication;

The port Link/Act indicator;

USB port status indication;

QSS security status.

Antenna

6 external detachable omni antenna

Size 243mm x 160mm x 33mm (L x W x H)

Wireless parameters

The basic functions of

Wireless switch;

SSID radio switch;

Working frequency band selection: 2.4GHz, 5GHz;

2.4GHz channel selection: 1-13; 5GHz channel selection: 149, 153, 157, 161, 165;

2.4GHz wireless optional mode: 11 BGN mixed

5GHz wireless optional mode: 11 an/ac mixed (default)

WDS wireless bridge

Wireless security

Wireless MAC address filtering;

Wireless security function switch;

64/128/152 WEP encryption;

WPA-PSK/WPA2-PSK, WPA/WPA2 security mechanism;

WPS security settings

Other functions

Support wireless roaming;

The wireless host status display;

1.75G 11AC Dual Band Gigabit Wireless Router
TL-WDR7500

  • 11AC, whole new generation of wireless technology , a better viewing experience
  • 2.4/5GHz dual-band technology, wireless speed up to 1.75Gbps
  • Gigabit wired ports , faster network transfer rate
  • 6 single-frequency antenna , the signal wider coverage , better signal .
  • Provides two USB ports , support for network storage sharing, multimedia servers, FTP servers and other functions
  • IP bandwidth control function , the free allocation of Internet Bandwidth
  • WDS function , easily expand wireless network
  • Hardware Specifications

    Protocol standards

    • IEEE 802.11n, IEEE 802.11g, IEEE 802.11b; IEEE 802.11.ac; IEEE 802.11.a
    • IEEE 802.3, IEEE 802.3u, IEEE 802.3ab;

    Wireless rate

    • 2.4GHz band : 450Mbps
    • 5GHz band : 1.3Gbps

    Interface

    • 4 10/100/1000M adaptive LAN port, support auto-flip (Auto MDI / MDIX);
    • 1 10/100/1000M Adaptive WAN port supports auto- flip (Auto MDI / MDIX);
    • Two USB 2.0 ports .

    Push button

    • Power switch ;
    • QSS button ;
    • Reset button.

    LED

    • Power indicator ;
    • SYS system instructions ;
    • 2.4GHz wireless status indicator ;
    • 5GHz wireless status indicator ;
    • Each port Link / Act instructions ;
    • USB port status indication ;
    • QSS security status indication.

    Antenna

    • 6 external omnidirectional antenna is not removable

    Size

    • 243mm x 160mm x 33mm (L x W x H)

    Radio parameters

    Basic functions

    • Wireless switch ;
    • SSID broadcasting switches ;
    • Operating band selection : 2.4GHz, 5GHz;
    • 2.4GHz channel selection :1-13; 5GHz channel selection : 149,153,157,161,165 ;
    • 2.4GHz wireless modes are available : 11 bgn mixed
    • 5GHz wireless modes are available : 11 an / ac mixed ( default

    Operating Mode

    • AP mode ;
    • WDS wireless bridge mode ;

    Wireless Security

    • Wireless MAC address filtering ;
    • Wireless security function switch ;
    • 64/128/152 bit WEP encryption ;
    • WPA-PSK/WPA2-PSK, WPA/WPA2 security mechanism ;
    • WPS Quick Secure Setup

    Other features

    • Support wireless roaming ;
    • Wireless host status display ;

    Wired Function

    Practical function

    • IP bandwidth control function ;
    • Peanut shell DDNS;

    Network Settings

    • WAN port connection type support : PPPoE, Dynamic IP, Static IP;
    • Dial-up Type: Automatic dialing , on-demand dialing, manual dialing , timing function ;
    • MAC address modification and cloning ;
    • VPN Pass-through;
    • Static routing ;

    DHCP settings

    • DHCP server ;
    • DHCP client ;
    • Client list ;
    • Static address assignment ;

    Network sharing

    • Network storage sharing ;
    • FTP server ;
    • Media server ;
    • Print server ;
    • Shared accounts ;

    Port Forwarding

    • Virtual servers ;
    • Special applications ;
    • DMZ host ;
    • UPnP settings ;

    Security Settings

    • IP and MAC address binding against ARP attacks ;
    • IP address filtering ;
    • Domain filtering ;
    • MAC address filtering ;
    • DoS attack prevention ;
    • FLOOD attack prevention ;
    • Ping packet control ;

    System Tools

    • Traffic statistics ;
    • System security log ;
    • Remote Web management ;
    • Configuration file import and export ;
